Diesel Generator 60kVA with Water Cooling Brushless Alternator
Three Phase for Factory Use
| 50KW DIESEL GENERATOR DETAILS |
| Model | 50GF | Start Method | DC 24 |
| Generator Prime Power(KW) | 50 | Output Current(A) | 90 |
| Standby Power(KW) | 55 | Voltage(V) | 400/230 |
| Power Factor | 0.8 | Phase | Three phase, Four Wires |
| Frequency(Hz) | 50/60 | Weight(kg) | 850 |
| Size(mm) | L | W | G |
| 1800 | 720 | 1450 |
| Diesel Engine Data |
| Manufacturer | Ricardo Engine | Model | R4105ZD |
| Rated Speed(Rpm) | 1500/1800 | Diesel Engine Max Power(KW/H) | 56 |
| Cylinder No. | 4 | Arrangement Type | In-line |
| Bore×Stroke(mm) | 105×125 | Displacement(L) | 4.33 |
| Intake Method | Turbocharged | Compression ratio | 16.0:1 |
| Fuel | Diesel Fuel | Full Load Consumption(g/kw.h) | ≤231 |
| Oil Capacity(L) | 15 | Start Method | Electrical |
| Engine Cooled Method | Radiator Max 40ºC,fans are driven by belt with safety guard. |
| Alternator Data |
| Manufacturer | Shanghai | Model | 50KW |
| Rated Power(KVA/KW) | 62.5/50 | Excitation Type | Brushless/Brush |
| Insulation Class | H | Protection Grade | IP22 |
| Unload Voltage Adjustment | ≥±5% | Stable Voltage Adjustment | ±1% |
| Efficiency (%) | 94.8 | Voltage Control Method | AVR |
Performance Feature
Engine and alternator shall be mounted on a same frame steel skid.
Built-in damper for anti-vibration.
Small size, low weight, easy for operation, installation and
maintenance.
World most famous brand diesel engine.
VOLVO PENTA, DOOSAN, DEUTZ, LOVOL, WUXI POWER, GOOGOL, CSR.
World famous brand AC alternator: Stamford, Marathon, Leroy Somer,
MVC.
Advanced and reliable controller: Key start, Auto start, AMF &
Remote control by PC with RS232 / 485.
Full range protect function and alarm shutdown feature.
Comply with GB/T2820-97, ISO8528 national standard and ISO9001
quality standard.
Alternator Feature
Brushless, 4 poles, rotation magnet.
IP21-23 enclosure is standard for all industrial alternators.
The insulation system is Class H.
Simple installation and maintenance, with easy access to terminals,
rotating diodes and coupling bolts.
Wide range of flange adaptors and single bearing disc coupling.
Standard 2/3 pitch windings avoid excessive neutral currents.
Optional accessories available for easy paralleling with mains or
other generators.
Optional permanent magnet generator ( PMG ) system provide constant
excitation under all condition.
AVR auto voltage regulator, auto exciter, auto adjustment.
Standard: BS5000, VDE0530, NEMA MG1-32, IEC34, IEC60034, AS1359.
Control System
GCS6410 is an Automatic Mains Failure module which is designed to
monitor the mains utility and on failure automatically starts the
generator and transfers the load. On return of the mains utility
the controller automatically returns the load to the mains and
stops the generator after a cool down period.
The module also monitors and protects the engine, indicating
operational status, fault conditions and metering on the front
panel LCD or LED's.
Ture RMS measuring
Configuration of parameters by front panel push buttons or
communication software
RS485, RS232, or USB port for remote communication.
Configurable fuel output energise to stop or energise to run.
Our customers include Africa, Southeast Asia, West Asia, South
America and other emerging developing countries. We are committed
to providing our customers with better quality, better price and
good products, and creating more value for our customers
1.We develops independently with 4100 series, British ricardo R4105
and R6105 series, the 6113 series and steel 6126 series diesel
engines.
2.Combined the advantages of domestic and foreign advanced diesel
engines , improved the fuel injection system, intake and exhaust
system, the cooling system to suit the seeds of various generating
sets.
3.High power, low fuel consumption, easy to start, equipped with
air filter rear.
4.High quality Silent box, ATS, trailer, battery, brush or without
brush as optional parts.
5.The generator can be equipped in factory, school, hospital,
farm,etc.
FAQ
1. What is your warranty period?
Our warranty period is 1 year or 1000 running hous, whichever comes
first(Excep the damageable spare parts of genset caused by
incorrect man-made operation).
2. Does your generator have global warranty?
Yes. Gensets powered by global brand engine which with the global
warranty service. And the alterntors Stamford, Leroy somer,
Meccalte, Marathon also have the global warranty service.
3. What is your payment terms?
T/T 30% advance payment, the balance 70% shall be paid before
shipment.
L/C Irrevocable L/C at sight.
4. What is your delivery time?
Our standard delivery time is 20 to 30 days. If you have urgent
demand, the delivery will be shorter depending on the requirements.
If you have special requirements, the delivery will be longer.
5. Can the generators be customized?
Yes. Our generators can be customized depending on customer's
detailed requirements. We can supply generators for rental
business, home use, inudstrial projects, army projects, power
station, etc. The generators we supply is suitable for indoor and
outdoor use, lower and high temperature environment.
